High efficiency 150W poly solar panel solar system

FOB Reference Price:Get Latest Price
US $0.36-0.45 / Watts | 5000 Watt/Watts the lowest price solar panel (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
RSESUN
Model Number:
RS6E150P
Material:
Polycrystalline Silicon
Size:
1484*669*35mm
Number of Cells:
36(4x9pcs)
Max. Power:
150w
Item Name:
solar electricity system
solar panel Maximum voltage:
18.54V
solar panel Maximum current:
8.09A
solar panel Open circuit voltage:
22.68V
solar panel Short circuit current:
8.82A
solar weight:
11.50kg
Frame Material:
Anodized aluminum alloy
Cell Type:
Polycrystalline 156x156mm 2 or 3 Busbars
Junction box:
Ip65 rated/past the TUV certificate
OEM Order:
Acceptable
Supply Ability
Supply Ability:
200000 Piece/Pieces per Week 150w poly solar panel
Packaging & Delivery
Packaging Details
1. Paper carton and wooden pallet for solar panels
2. All our solar panel packaging are of international standard only for solar panels
Port
Shanghai
Lead Time :
Within 10 to 15 working days after receiving the deposit
Company Information

       Suzhou Resun Solar Co., Ltd. is specialized in manufacturing solar panels from 3W to 330W since 2007 with CE/TUV certificates.And the solar panels have been exported to Europe, South Africa, Middle-East, South Asia ect. successfully, and get good feedback.

Product Description

Product Name: High efficiency 150W poly solar panel solar system

  Electrical Characteristics



150W poly solar panel with high efficiency:

Maximum power at STC (Pmax)                                  150W

Optimum operating voltage (Vmp)                              18.54V

Optimum operating current (Imp )                               8.09A

Open-circuit voltage (Voc )                                            22.68V

Short-circuit current (Isc )                                             8.82A

Short-circuit current temperature coefficient              ( 0.065±0.015)%/°c

Open-circuit voltage temperature coefficient               -(80±10)mV/°c

Peak power temperature coefficient                            -(0.5±0.05)%/°c

NOCT (Air 20°c; Sun 0.8kW/m wind 1m/s)                     47±2°c

Operating temperature                                                  -40°c to 85°c

Maximum system voltage                                             1000V DC

Power tolerance                                                             ±3%

306459931_914

Advantages

We can produce the solar panel from 2W~305W according customer’s size and requirements;
1)Mono crystalline or poly crystalline for choice.
2)Power range: from 2WP to 305WP, voltage 9V/12V/18V/36V
3)10 year warranty, 25 year 70%~80% of peak power
4)Standard test condition: AM1.5 100mW/cm2 25°C;
5)Tolerance: +/-5%, solar cell’s efficiency up to above 16%.
6)Certification: CE, TUV, ISO9001:2008

Installation


Functions

        This model of solar panel can be used for solar home system.solar system on grid&off grid.  As new energy now,it is popular in many countries such as India,Africa,Middle East countries etc.
How solar work.jpg Some Project Performance:

Usage (2).jpg

Packaging & Shipping


Delivery:  Material in stock for solar panel can be produce (procedure 5-20days) right away after pre-payment confirmation. COSCO Mearsk MSC ship to worldwide for safe shipping,for solar panel don't worry about package damager or loss. It takes about 15-40 days to worldwide, Please note us your contact details include your phone number for easy contacting from shipping company officer.

Shipping:

By Sea

Delivery from Shanghai or Ningbo seaport

By Air

Departure from Shanghai Pudong Airport

By Express

Post by DHL, EMS, UPS, TNT.

Production Flow

Production Line 1.jpg

Exhibition Show


We are manufacturers and wholesalers of solar panels and renewable energy products. Our solar panel business has been established since 2007. Our engineers are experienced in solar and related accessories, if you buy from us you deal with not just a seller; the whole technical team for solar panel is behind you and your business. We would like to be your best supplier of solar panel in China.
